| Nombor Bahagian | GV101WXB-NN0-3GP0 |
| Jenama | BOE |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | GV101WXB-NN0-3GP0 |
| saiz panel | 10.1" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1280(RGB)×800, WXGA, 149PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 216.96(W)×135.6(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 221.96(W)×144.43(H) ×1.06(D) mm |
| permukaan | Without Polarizer, Hard coating |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| warna paparan | 16.7M 50% NTSC |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COG Built-in 2 source chips |
| berat panel | - |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
