| Nombor Bahagian | G270QAN02.0 |
| Jenama | AUO |
| Saiz | 27.0 |
| Permohonan | Industrial |
| Resolusi | 2560×1440 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | LVDS |
| pengilang | AUO |
| nama model | G270QAN02.0 |
| saiz skrin | 27.0 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 2560(RGB)×1440 (Quad-HD) 108PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 596.74 × 335.66 (H×V) |
| garis besar (mm) | 606.44 × 355.56 × 15.03 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 8/8 (Typ.)(Tr/Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 99% sRGB |
| lampu latar | 4 strings WLED , 30K hours , No Driver |
| jisim | 3.50Kgs (Typ.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (4 ch, 8-bit) , 70 pins Connector |
| bekalan voltan | 5.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 55 °C Operating Temp.: 0 ~ 50 °C |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SLC2 | LG Display | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270HGE-L10 | Innolux | 27.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| M270QAN01.1 | AUO | 27.0 | 3840×2160 |
