| Nombor Bahagian | G270QAN01.0 |
| Jenama | AUO |
| Saiz | 27.0 |
| Permohonan | Industrial |
| Resolusi | 2560×1440 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 4 |
| Antara muka | LVDS |
| jenama panel | AUO |
| saiz panel | 27.0" |
| resolusi | 2560(RGB)×1440, Quad-HD, 108PPI |
| kawasan paparan | 596.74(W)×335.66(H) mm |
| saiz garis besar | 630(W)×368.2(H) ×15.6(D) mm |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 100% Adobe RGB |
| kekerapan | 60Hz |
| berat panel | 3.15Kgs (Typ.) |
| antara muka isyarat | LVDS (4 ch, 8-bit) , 92 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | G270QAN01.0 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 601.6(W)×340.15(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | AHVA, Normally Black, Transmissive |
| masa tindak balas | 8/8 (Typ.)(Tr/Td) |
| jenis lampu | 4 strings WLED , 30K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDA2 | LG Display | 27.0 | 2560×1440 |
| LM270WQ3-SLB2 | LG Display | 27.0 | 2560×1440 |
| M270DAN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.3 | AUO | 27.0 | 2560×1440 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| P270MWN1 R0 | IVO | 27.0 | 1920×1080 |
