| Nombor Bahagian | G270HAN01.2 |
| Jenama | AUO |
| Saiz | 27.0 |
| Permohonan | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | 22S4P |
| Antara muka | LVDS |
| pengilang | AUO |
| nama model | G270HAN01.2 |
| saiz skrin | 27.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 81PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 597.888 × 336.312 (H×V) |
| garis besar (mm) | 611.48 × 355.81 × 13.3 (H×V×D) |
| kawasan bezel (mm) | 601.49 × 339.91 (H×V) |
| rawatan | Antiglare |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 14 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.7M 72% NTSC |
| lampu latar | 22S4P WLED , 50K hours , No Driver |
| jisim | 2.87Kgs (Typ.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (2 ch, 8-bit) , Connector 30 pins |
| bekalan voltan | 5.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF2-TLA5 | LG Display | 27.0 | 1920×1080 |
| LM270WF5-SSC1 | LG Display | 27.0 | 1920×1080 |
| LM270WF6-SSZ1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDC2 | LG Display | 27.0 | 2560×1440 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.1 | AUO | 27.0 | 2560×1440 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| M270HW02 V0 | AUO | 27.0 | 1920×1080 |
