| Nombor Bahagian | G270HAN01.0 |
| Jenama | AUO |
| Saiz | 27.0 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 1.07B |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | G270HAN01.0 |
| saiz panel | 27.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 81PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 597.888(W)×336.312(H) mm |
| pembukaan bezel | 602(W)×340.4(H) mm |
| saiz garis besar | 630(W)×368.2(H) ×23.4(D) mm |
| permukaan | Antiglare |
| kecerahan | 1000 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | AHVA, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 14 (Typ.)(Tr+Td) |
| warna paparan | 1.07B 87% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 3.40Kgs (Typ.) |
| permohonan | Industrial Outdoor High Brightness |
| antara muka isyarat | LVDS , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
