| Nombor Bahagian | G229HAN01.0 |
| Jenama | AUO |
| Saiz | 22.9 |
| Permohonan | Industrial Stretched |
| Resolusi | 1920×165 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | AUO |
| saiz panel | 22.9" |
| resolusi | 1920(RGB)×165, 84PPI |
| kawasan paparan | 578.88(W)×49.7475(H) mm |
| saiz garis besar | 587.08(W)×62.05(H) ×10.71(D) mm |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.7M 72% NTSC |
| kekerapan | 60Hz |
| berat badan | 460g (Typ.) |
| model panel | G229HAN01.0 |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 580.88(W)×51.75(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| mod paparan | AHVA, Normally Black, Transmissive |
| masa tindak balas | 13/12 (Typ.)(Tr/Td) |
| jenis lampu | WLED , 70K hours , With LED Driver |
| skrin sentuh | Without |
| permohonan | Industrial Stretched Bar LCD |
