| Nombor Bahagian | G190EG02 V104 |
| Jenama | AUO |
| Saiz | 19.0 |
| Permohonan | Industrial Medical I |
| Resolusi | 1280×1024 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 2000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | AUO |
| saiz skrin | 19.0 inch |
| nombor piksel | 1280(RGB)×1024 (SXGA) 86PPI |
| kawasan aktif (mm) | 376.32 × 301.056 (H×V) |
| kawasan bezel (mm) | 380.32 × 305.06 (H×V) |
| kecerahan | 350 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 70% NTSC |
| jisim | 1.74Kgs (Typ.) |
| kadar segar semula | 60Hz |
| jenis isyarat | LVDS (2 ch, 8-bit) , 30 pins Connector |
| bekalan voltan | 5.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 70 °C Operating Temp.: -15 ~ 70 °C |
| nama model | G190EG02 V104 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 396 × 324 × 15.8 (H×V×D) |
| rawatan | Antiglare |
| nisbah kontras | 2000 : 1 (Typ.) (TM) |
| tindak balas | 15/5 (Typ.)(Tr/Td) ms |
| mod kerja | MVA, Normally Black, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial Medical Imaging |
| skrin sentuh | Without |
