| Nombor Bahagian | G185XW01 V201 |
| Jenama | AUO |
| Saiz | 18.5 |
| Permohonan | Industrial |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | G185XW01 V201 |
| saiz panel | 18.5" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1366(RGB)×768, WXGA, 84PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 409.8(W)×230.4(H) mm |
| pembukaan bezel | 413.4(W)×234.0(H) mm |
| saiz garis besar | 430.4(W)×254.7(H) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 85/85/80/80 (Typ.)(CR≥10) |
| mod paparan | TN, Normally White, Transmissive |
| pandangan terbaik pada | - |
| masa tindak balas | 3.5/1.5 (Typ.)(Tr/Td) |
| warna paparan | 16.7M 70% NTSC |
| jenis lampu | WLED , 50K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 1.44Kgs (Max.) |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 8-bit) , 30 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 60 °C |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| G185XW01 V2 | AUO | 18.5 | 1366×768 |
| HM185WX1-400 | BOE | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC190WH1-TLC1 | LG Display | 18.5 | 1366×768 |
| LTA185AT01 | Samsung | 18.5 | 1366×768 |
| LTM185AT04 | Samsung | 18.5 | 1366×768 |
| M185XW01 V3 | AUO | 18.5 | 1366×768 |
| M185XW01 V4 | AUO | 18.5 | 1366×768 |
| M185XW01 V6 | AUO | 18.5 | 1366×768 |
