| Nombor Bahagian | G170ETN03.1 |
| Jenama | AUO |
| Saiz | 17.0 |
| Permohonan | Industrial |
| Resolusi | 1280×1024 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AUO |
| model | G170ETN03.1 |
| saiz pepenjuru | 17.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×1024 [SXGA] 96PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 337.92(H)×270.336(V) mm |
| garis besar malap. | 358.5(H)×296.5(V) ×10.8(D) mm |
| kawasan bezel | 341.7(H)×274.1(V) mm |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 3.8/1.2 (Typ.)(Tr/Td) |
| sudut pandangan | 85/85/80/80 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 16.7M 72% NTSC |
| sumber cahaya | WLED [9S4P] , 30K hours , W/O Driver |
| berat badan | 1.27Kgs (Typ.) |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (2 ch, 8-bit) , 30 pins Connector |
| bekalan kuasa | 5.0V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
