| Nombor Bahagian | G156XTN01.0 |
| Jenama | AUO |
| Saiz | 15.6 |
| Permohonan | Industrial |
| Resolusi | 1366×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AUO |
| model | G156XTN01.0 |
| saiz pepenjuru | 15.6 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1366(RGB)×768 [WXGA] 100PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 344.232(H)×193.536(V) mm |
| garis besar malap. | 363.8(H)×215.9(V) ×9.6(D) mm |
| kawasan bezel | 350.4(H)×196.94(V) mm |
| rawatan | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| kecerahan | 400 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | 6 o'clock |
| masa tindak balas | 10 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/50/80 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 16.7M 62% NTSC |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat badan | 860g (Typ.) |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
