| Nombor Bahagian | G156HAB02.5 |
| Jenama | AUO |
| Saiz | 15.6 |
| Permohonan | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, Assemb |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama | AUO |
| model | G156HAB02.5 |
| saiz pepenjuru | 15.6 inch |
| menaip | a-Si TFT-LCD, Assembly |
| format piksel | 1920(RGB)×1080 [FHD] 141PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 344.16(H)×193.59(V) mm |
| garis besar malap. | - |
| kawasan bezel | - |
| rawatan | Hard coating (5H) |
| kecerahan | - |
| nisbah kontras | 800:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod operasi | - |
| warna sokongan | 16.2M |
| sumber cahaya | WLED , 50K hours , With LED Driver |
| berat badan | - |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | On-Cell Touch |
| jenis antara muka | eDP (2 Lanes) , eDP1.2 |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
