| Nombor Bahagian | G156HAB01.0 |
| Jenama | AUO |
| Saiz | 15.6 |
| Permohonan | Industrial |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD , Assem |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | AUO |
| saiz panel | 15.6" |
| resolusi | 1920(RGB)×1080, FHD, 141PPI |
| kawasan paparan | 344.16(W)×193.59(H) mm |
| saiz garis besar | 361(W)×227(H) ×4.9(D) mm |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan terbaik pada | Symmetry |
| warna paparan | 16.2M 45% NTSC |
| kekerapan | 60Hz |
| berat panel | 620g (Max.) |
| antara muka isyarat | eDP (2 Lanes) , eDP1.2 , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| model panel | G156HAB01.0 |
| jenis panel | a-Si TFT-LCD , Assembly |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| permukaan | Hard coating (7H) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | - |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| jenis lampu | WLED , 30K hours , With LED Driver |
| skrin sentuh | On-Cell Touch |
| permohonan | Industrial |
