| Nombor Bahagian | G150XAN01.2 |
| Jenama | AUO |
| Saiz | 15.0 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | LCM, a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | AUO |
| nama model | G150XAN01.2 |
| saiz skrin | 15.0 inch |
| jenis skrin | LCM, a-Si TFT-LCD |
| nombor piksel | 1024(RGB)×768 (XGA) 85PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 304.128 × 228.096 (H×V) |
| garis besar (mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| kawasan bezel (mm) | 309.9 × 236.3 (H×V) |
| rawatan | Antiglare, Hard coating (3H) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 25 (Typ.)(Tr+Td) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | AHVA, Normally Black, Transmissive |
| kedalaman warna | 16.2M 60% NTSC |
| lampu latar | WLED , 50K hours , With LED Driver |
| jisim | 660g (Max.) |
| digunakan untuk | Industrial |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (1 ch, 8-bit) , Connector 30 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
