| Nombor Bahagian | G104XVN01.1 |
| Jenama | AUO |
| Saiz | 10.4 |
| Permohonan | Industrial |
| Resolusi | 1024×768 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 3000:1 |
| Warna | 262K/16.2M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | G104XVN01.1 |
| saiz panel | 10.4" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1024(RGB)×768, XGA, 123PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 210.4(W)×157.8(H) mm |
| pembukaan bezel | 215.4(W)×161.8(H) mm |
| saiz garis besar | 238.6(W)×175.8(H) ×7(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | - |
| nisbah kontras | 3000:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | AMVA3, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 20/10 (Typ.)(Tr/Td) |
| warna paparan | 262K/16.2M |
| jenis lampu | WLED , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Industrial |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| G104X1-L01 | Innolux | 10.4 | 1024×768 |
| G104X1-L02 | Innolux | 10.4 | 1024×768 |
| G104X1-L03 | Innolux | 10.4 | 1024×768 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| G104XGE-L05 | Innolux | 10.4 | 1024×768 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| LQ104V1DC41 | SHARP | 10.4 | 640×480 |
| LQ104X2LX05B | SHARP | 10.4 | 1024×768 |
| NL6448BC33-53 | NLT | 10.4 | 640×480 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
