| Nombor Bahagian | G101STN01.D |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | AUO |
| saiz skrin | 10.1 inch |
| nombor piksel | 1024(RGB)×600 (WSVGA) 117PPI |
| kawasan aktif (mm) | 222.72 × 125.28 (H×V) |
| kawasan bezel (mm) | 226.43 × 128.1 (H×V) |
| kecerahan | 450 cd/m² (Typ.) |
| sudut pandangan | 70/70/60/60 (Typ.)(CR≥10) |
| pandangan yang baik di | - |
| kedalaman warna | 262K/16.7M 45% NTSC |
| jisim | 180g (Typ.) |
| kadar segar semula | 60Hz |
| jenis isyarat | LVDS (1 ch, 6/8-bit) , 40 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| nama model | G101STN01.D |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 235 × 143 × 5.2 (H×V×D) |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 500 : 1 (Typ.) (TM) |
| tindak balas | 7/9 (Typ.)(Tr/Td) ms |
| mod kerja | TN, Normally White, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Industrial |
| skrin sentuh | Without |
