| Nombor Bahagian | G101STN01.5 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | Industrial |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 500:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | Parallel |
| jenama | AUO |
| saiz pepenjuru | 10.1 inch |
| format piksel | 1024(RGB)×600 [WSVGA] 117PPI |
| kawasan aktif | 222.72(H)×125.28(V) mm |
| kawasan bezel | 226.43(H)×128.1(V) mm |
| kecerahan | 350 cd/m² (Typ.) |
| arah pandang | - |
| sudut pandangan | 70/70/60/60 (Typ.)(CR≥10) |
| warna sokongan | 262K/16.7M 45% NTSC |
| berat badan | 340g (Max.) |
| kadar bingkai | 60Hz |
| jenis antara muka | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| bekalan kuasa | 3.3/10/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| persekitaran | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | G101STN01.5 |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 235(H)×143(V) ×5.5(D) mm |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 500:1 (Typ.) (TM) |
| masa tindak balas | 7/9 (Typ.)(Tr/Td) |
| mod operasi | TN, Normally White, Transmissive |
| sumber cahaya | WLED , 15K hours , W/O Driver |
| direka untuk | Industrial |
| panel sentuh | Without |
