| Nombor Bahagian | G084SN05 V7 |
| Jenama | AUO |
| Saiz | 8.4 |
| Permohonan | IA |
| Resolusi | 800×600 |
| Komposisi | LCM |
| Kecerahan | 450 |
| CR | 600:1 |
| Warna | 262K/16.2M |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | G084SN05 V7 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 8.4 inch |
| resolusi | 800(RGB)×600 , SVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 170.4×127.8 mm |
| garis besar | 203×142.5×8.3 mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 450 cd/m² (Typ.) |
| nisbah kontras | 600:1 (Typ.) |
| warna paparan | 262K/16.2M (6-bit / 6-bit + FRC), CIE193145% |
| masa tindak balas | 20/10 (Typ.)(Tr/Td) |
| sudut pandangan | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 2 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6/8-bit), 20 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | IA |
| G084SN02 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V0 | AUO | 8.4 | 800×600 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| G084SN03 V2 | AUO | 8.4 | 800×600 |
| G084SN03 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V5 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| G084SN05 V8 | AUO | 8.4 | 800×600 |
| G084SN05 V9 | AUO | 8.4 | 800×600 |
| AA121SU01 | Mitsubishi | 12.1 | 800×600 |
| EDMGRB8KHF | Panasonic | 7.8 | 640×480 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G133IGE-L03 | Innolux | 13.3 | 1280×800 |
| HG2401288V1-B-LWH | Other | 4.8 | 240×128 |
| LB150X03-TL02 | LG Display | 15.0 | 1024×768 |
| LQ104V1LG81 | SHARP | 10.4 | 640×480 |
| LTA121C250F | TOSHIBA | 12.1 | 1024×768 |
| NL10276BC24-19D | NLT | 12.1 | 1024×768 |
| NL6448BC28-01 | NLT | 9.0 | 640×480 |
