| Nombor Bahagian | G070VAN01.0 |
| Jenama | AUO |
| Saiz | 7.0 |
| Permohonan | Industrial |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1300:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | AUO |
| model | G070VAN01.0 |
| saiz pepenjuru | 7.0 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 800×480(RGB) [WVGA] 133PPI |
| konfigurasi | RGB Horizontal Stripe |
| kawasan aktif | 152.4(H)×91.44(V) mm |
| garis besar malap. | 166.6(H)×107(V) ×10(D) mm |
| kawasan bezel | 154.2(H)×93.24(V) mm |
| rawatan | Antiglare |
| kecerahan | 480 cd/m² (Typ.) |
| nisbah kontras | 1300:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 11/19 (Max.)(Tr/Td) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod operasi | AHVA, Normally Black, Transmissive |
| warna sokongan | 262K/16.7M 70% NTSC |
| sumber cahaya | WLED [7S2P] , 50K hours , W/O Driver |
| berat badan | 175±10%g |
| direka untuk | Industrial |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
