| Nombor Bahagian | EV190E0M-N50 |
| Jenama | BOE |
| Saiz | 19.0 |
| Permohonan | Medical Imaging |
| Resolusi | 1280×1024 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | Grayscale |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | EV190E0M-N50 |
| saiz panel | 19.0" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(LCR)×1024, SXGA, 86PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 374.784(W)×299.827(H) mm |
| pembukaan bezel | 378.8(W)×303(H) mm |
| saiz garis besar | 396(W)×324(H) ×10.4(D) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 1300 cd/m² (Typ.) |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 14 (Typ.)(G to G) |
| warna paparan | Grayscale |
| jenis lampu | WLED , 50K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 1.69Kgs (Typ.) |
| permohonan | Medical Imaging |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltan masukan | 5.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
