| Nombor Bahagian | EV121WXM-N12 |
| Jenama | BOE |
| Saiz | 12.1 |
| Permohonan | Medical Imaging |
| Resolusi | 1280×800 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama | BOE |
| model | EV121WXM-N12 |
| saiz pepenjuru | 12.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×800 [WXGA] 124PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 261.12(H)×163.2(V) mm |
| garis besar malap. | 277.7(H)×180.6(V) ×9.2(D) mm |
| kawasan bezel | 264.12(H)×166.2(V) mm |
| rawatan | Antiglare (Haze 25%) |
| kecerahan | 500 cd/m² (Typ.) |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod operasi | ADS, Normally Black, Transmissive |
| warna sokongan | 262K/16.7M 100% sRGB |
| sumber cahaya | WLED [12S4P] , 50K hours , With LED Driver |
| berat badan | TBD |
| direka untuk | Medical Imaging |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
