| Nombor Bahagian | ET024012DMA |
| Jenama | EDT |
| Saiz | 2.4 |
| Permohonan | Handheld & PDA |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 820:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | 8/9/16/18-bit |
| jenama | EDT |
| model | ET024012DMA |
| saiz pepenjuru | 2.4 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 240(RGB)×320 [QVGA] 166PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 36.72(H)×48.96(V) mm |
| garis besar malap. | 42.72(H)×60.4(V) mm |
| kawasan bezel | 37.72(H)×49.96(V) mm |
| rawatan | - |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 820:1 (Typ.) (TM) |
| arah pandang | - |
| masa tindak balas | 35 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/70/70 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 262K 59% NTSC |
| sumber cahaya | WLED [4S1P] , 10K hours , W/O Driver |
| berat badan | - |
| direka untuk | Handheld & PDA |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | 8/9/16/18-bit 8080 parallel , 35 pins FPC |
| bekalan kuasa | 3.0/3.0V (Typ.)(VCI/IOVCC) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| 24QVF1J | SII | 2.4 | 240×320 |
| AMCB004 | Samsung | 2.4 | 240×320 |
| AMCE002 | Samsung | 2.4 | 240×320 |
| C0240QGLG-T | CMEL | 2.4 | 240×320 |
| DLC0240LZG-4 | Other | 2.4 | 240×320 |
| LTM024P339 | TOSHIBA | 2.4 | 240×320 |
| RGS24128022YR000 | RiTdisplay | 2.4 | 128×22 |
| RX024A-03 | ROGIN | 2.4 | 480×234 |
| TD024THEB5 | TPO | 2.4 | 480×240 |
| UG-2864ASWPG01 | WiseChip | 2.4 | 128×64 |
