| Nombor Bahagian | EMA-101402-01 |
| Jenama | eMagin |
| Saiz | 0.77 |
| Permohonan | HMD VR AR |
| Resolusi | 1280×1024 |
| Komposisi | OLED, Si-OLED |
| Kecerahan | |
| CR | 1000:1 |
| Warna | Grayscale(G) |
| Lampu latar | self |
| Antara muka | Parallel |
| pengilang | eMagin |
| nama model | EMA-101402-01 |
| saiz skrin | 0.77 inch |
| jenis skrin | OLED, Si-OLED |
| nombor piksel | 1280(LCR)×1024 (SXGA) 2116PPI |
| susunan | LCR Vertical Stripe |
| kawasan aktif (mm) | 15.36 × 12.29 (H×V) |
| garis besar (mm) | 22.9 × 16.4 (H×V×D) |
| kecerahan | 5000 cd/m² (Typ.) |
| nisbah kontras | 1000 : 1 (Min.) (TM) |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | Symmetry |
| mod kerja | - |
| kedalaman warna | Grayscale(G) |
| lampu latar | self |
| jisim | 2.50g (Typ.) |
| digunakan untuk | HMD VR AR |
| kadar segar semula | 85Hz |
| skrin sentuh | Without |
| jenis isyarat | Parallel RGB , Connector 50 pins |
| bekalan voltan | 2.5/5/-1.4/-2.0V (Typ.)(VDD/VAN/VCOM/VPG) |
| maks. penilaian | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
