| Nombor Bahagian | EMA-101201 |
| Jenama | eMagin |
| Saiz | 0.63 |
| Permohonan | HMD VR AR |
| Resolusi | 1280×1024 |
| Komposisi | Si-OLED, OLED |
| Kecerahan | |
| CR | 1000:1 |
| Warna | Grayscale |
| Lampu latar | self |
| Antara muka | LVDS |
| jenama | eMagin |
| model | EMA-101201 |
| saiz pepenjuru | 0.63 inch |
| menaip | Si-OLED, OLED |
| format piksel | 1280(LCR)×1024 [SXGA] 2619PPI |
| konfigurasi | LCR Vertical Stripe |
| kawasan aktif | 12.4(H)×9.945(V) mm |
| garis besar malap. | 19.5(H)×14.8(V) ×5.4(D) mm |
| kecerahan | 900 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | - |
| sudut pandangan | - |
| mod operasi | - |
| warna sokongan | Grayscale 52% NTSC |
| sumber cahaya | self |
| berat badan | 3.00g (Typ.) |
| direka untuk | HMD VR AR |
| kadar bingkai | - |
| panel sentuh | Without |
| jenis antara muka | LVDS (1 ch, 8-bit) , 30 pins Connector |
| bekalan kuasa | 5/1.8/-1.5V (Typ.)(VDC/VDD/VPG) |
| persekitaran | Operating Temperature: -45 ~ 70 °C ; Storage Temperature: -55 ~ 90 °C |
