| Nombor Bahagian | EMA-101126 |
| Jenama | eMagin |
| Saiz | 0.59 |
| Permohonan | HMD VR AR |
| Resolusi | 800×600 |
| Komposisi | Si-OLED, OLED |
| Kecerahan | |
| CR | 1000:1 |
| Warna | Grayscale |
| Lampu latar | self |
| Antara muka | Parallel |
| jenama panel | eMagin |
| model panel | EMA-101126 |
| saiz panel | 0.59" |
| jenis panel | Si-OLED, OLED |
| resolusi | 800(LCR)×600, SVGA, 1693PPI |
| format piksel | LCR Vertical Stripe |
| kawasan paparan | 12(W)×9(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 18(W)×16(H) ×5.4(D) mm |
| permukaan | - |
| kecerahan | 900 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | - |
| mod paparan | - |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | - |
| warna paparan | Grayscale 52% NTSC |
| jenis lampu | self |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 2.00g (Typ.) |
| permohonan | HMD VR AR |
| antara muka isyarat | Parallel RGB (1 ch, 8-bit) , 40 pins Connector |
| voltan masukan | 1.8/5.0V (Typ.)(VDD1.8/VDD5) |
| persekitaran | Operating Temp.: -45 ~ 70 °C ; Storage Temp.: -55 ~ 90 °C |
