| Nombor Bahagian | EMA-100810-01 |
| Jenama | eMagin |
| Saiz | 0.86 |
| Permohonan | HMD VR AR |
| Resolusi | 1920×1200 |
| Komposisi | OLED , Si-OLED |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | self |
| Antara muka | LVDS |
| pengilang | eMagin |
| saiz skrin | 0.86 inch |
| nombor piksel | 1920(RGB)×1200 (WUXGA) 2645PPI |
| kawasan aktif (mm) | 18.432 × 11.52 (H×V) |
| kecerahan | 140 cd/m² (Typ.) |
| sudut pandangan | - |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 48% NTSC |
| jisim | 3.00g |
| kadar segar semula | 85Hz |
| jenis isyarat | LVDS , 40 pins Connector |
| bekalan voltan | 1.8/5.0/-1.5V (Typ.)(VDD/VAN/VPG) |
| maks. penilaian | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
| nama model | EMA-100810-01 |
| jenis skrin | OLED , Si-OLED |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 26.05 × 17.35 × 5.44 (H×V×D) |
| nisbah kontras | 1000 : 1 (Min.) (TM) |
| tindak balas | - |
| mod kerja | - |
| lampu latar | self |
| digunakan untuk | HMD VR AR |
| skrin sentuh | Without |
