| Nombor Bahagian | EC312TT2 |
| Jenama | E Ink |
| Saiz | 31.2 |
| Permohonan | Digital Signage |
| Resolusi | 1280×720 |
| Komposisi | EPD, EPD |
| Kecerahan | |
| CR | 13:1 |
| Warna | 4096 |
| Lampu latar | No |
| Antara muka | Parallel |
| pengilang | E Ink |
| nama model | EC312TT2 1 Compatible |
| saiz skrin | 31.2 inch |
| jenis skrin | EPD, EPD |
| nombor piksel | 1280×720 (WXGA) 47PPI |
| susunan | Rectangle |
| kawasan aktif (mm) | 691.2 × 388.8 (H×V) |
| garis besar (mm) | 697.2 × 402.8 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Hard coating |
| kecerahan | - |
| nisbah kontras | 13:1 (Typ.) (RF) |
| sudut pandangan | - |
| tindak balas | - |
| pandangan yang baik di | - |
| mod kerja | Reflective |
| kedalaman warna | 4096 13% NTSC |
| lampu latar | No B/L |
| jisim | 800g (Typ.) |
| digunakan untuk | Digital Signage |
| kadar segar semula | 50Hz |
| skrin sentuh | Without |
| jenis isyarat | Parallel Data (2ch, 8-bit) , Connector 200 pins |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -25 ~ 70 °C Operating Temp.: 0 ~ 50 °C |
