| Nombor Bahagian | DV550FHM-NV6 |
| Jenama | BOE |
| Saiz | 55 |
| Permohonan | Video Wall |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | BOE |
| nama model | DV550FHM-NV6 |
| saiz skrin | 55 inch |
| jenis skrin | LCM , a-Si TFT-LCD |
| nombor piksel | 1920(RGB)×1080 (FHD) 40PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 1209.6 × 680.4 (H×V) |
| garis besar (mm) | 1211.3 × 682.1 × 57.1 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 700 cd/m² (Typ.) |
| nisbah kontras | 1200 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 8 (Typ.)(G to G) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | ADS, Normally Black, Transmissive |
| kedalaman warna | 16.7M 72% NTSC |
| lampu latar | WLED , With LED Driver |
| jahitan penyambung | 1.7 mm (active to active seam) |
| digunakan untuk | Video Wall |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| jenis isyarat | LVDS (2 ch, 8-bit) , 51 pins Connector |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
