| Nombor Bahagian | DV460FHM-NV2 |
| Jenama | BOE |
| Saiz | 46 |
| Permohonan | Video Wall |
| Resolusi | 1920×1080 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | LVDS |
| pengilang | BOE |
| saiz skrin | 46 inch |
| nombor piksel | 1920(RGB)×1080 (FHD) 47PPI |
| kawasan aktif (mm) | 1018.08 × 572.67 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 500 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 95% sRGB |
| jahitan penyambung | 0.9 mm (active to active seam) |
| kadar segar semula | 60Hz |
| jenis isyarat | LVDS (2 ch, 8-bit) , 51 pins Connector |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | DV460FHM-NV2 |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 1018.96 × 573.55 × 58.3 (H×V×D) |
| rawatan | Antiglare (Haze 25%), Hard coating (2H) |
| nisbah kontras | 1200 : 1 (Typ.) (TM) |
| tindak balas | 8 (Typ.)(G to G) ms |
| mod kerja | ADS, Normally Black, Transmissive |
| lampu latar | WLED , 50K hours , With LED Driver |
| digunakan untuk | Video Wall |
| skrin sentuh | Without |
| HV460WUC-200 | BOE | 46 | 1920×1080 |
| LSC460HW01 | Samsung | 46 | 1920×1080 |
| LTA460HM03 | Samsung | 46 | 1920×1080 |
| LTA460HM06 | Samsung | 46 | 1920×1080 |
| LTA460HQ23 | Samsung | 46 | 1920×1080 |
| LTF460HF08 | Samsung | 46 | 1920×1080 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
| T460HW04 V0 | AUO | 46 | 1920×1080 |
| T460HW08 V0 | AUO | 46 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
