| Nombor Bahagian | DV430FHB-R00 |
| Jenama | BOE |
| Saiz | 43 |
| Permohonan | Digital Signage |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | DV430FHB-R00 |
| saiz panel | 43" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1920(RGB)×1080, FHD, 51PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 940.896(W)×529.254(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 949.5(W)×541.75(H) ×1.4(D) mm |
| permukaan | Antiglare (Haze 1%), Hard coating (3H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| ketransmisian | 6.0% (Typ.) |
| warna paparan | 16.7M |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COFBuilt-in 6 source chips |
| berat panel | 1.51Kgs (Typ.) |
| permohonan | Digital Signage |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -20 ~ 70 °C |
