| Nombor Bahagian | DV363FBB-N00 |
| Jenama | BOE |
| Saiz | 36.3 |
| Permohonan | Digital Signage |
| Resolusi | 1216×2160 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | DV363FBB-N00 |
| saiz panel | 36.3" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1216(RGB)×2160, 68PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 452.352(W)×803.52(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 464.352(W)×809.62(H) mm |
| permukaan | Antiglare (Haze 1%) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8 (Typ.)(G to G) |
| kedalaman kaca | 0.50+0.50 mm |
| ketransmisian | 5.1% (Typ.)(with Polarizer) |
| warna paparan | 16.7M 72% NTSC |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COGBuilt-in 4 source chips |
| berat panel | 1.20Kgs (Typ.) |
| permohonan | Digital Signage |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 51 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
