| Nombor Bahagian | DV212FBB-N10 |
| Jenama | BOE |
| Saiz | 21.2 |
| Permohonan | Digital Signage Stre |
| Resolusi | 1920×360 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1200:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | LVDS |
| jenama panel | BOE |
| model panel | DV212FBB-N10 |
| saiz panel | 21.2" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 1920(RGB)×360, 92PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 529.416(W)×99.265(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 537.216(W)×109.6(H) mm |
| permukaan | Antiglare (Haze 25%) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1200:1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| mod paparan | HADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 8 (Typ.)(G to G) |
| kedalaman kaca | - |
| ketransmisian | 4.8% (Typ.)(with Polarizer) |
| warna paparan | 16.7M 72% NTSC |
| jenis lampu | No B/L |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| ic pemandu | COF Built-in 6 source + 1 gate chips |
| berat panel | 200g (Typ.) |
| permohonan | Digital Signage Stretched Bar LCD |
| antara muka isyarat | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltan masukan | 12.0V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
