| Nombor Bahagian | DMF5005N-EB |
| Jenama | Kyocera |
| Saiz | 5.2 |
| Permohonan | IA |
| Resolusi | 240×64 |
| Komposisi | LCM |
| Kecerahan | 65 |
| CR | 7:1 |
| Warna | Monochrome |
| Lampu latar | EL |
| Antara muka | CPU |
| jenama panel | OPTREX |
| model panel | DMF5005N-EB |
| jenis panel | STN-LCD , LCM |
| saiz panel | 5.2 inch |
| resolusi | 240×64 |
| mod paparan | STN, Transflective |
| kawasan aktif | 127.16×33.88 mm |
| garis besar | 180×65×12 mm |
| permukaan | |
| kecerahan | 65 cd/m² (Typ.) |
| nisbah kontras | 7:1 (Typ.)(Transmissive) |
| warna paparan | Monochrome (1-bit) |
| masa tindak balas | 160/160 (Typ.)(Tr/Td) |
| sudut pandangan | 34/32/36/35 (Typ.)(CR≥2)(L/R/U/D) |
| kekerapan | 70Hz |
| jenis lampu | EL |
| antara muka isyarat | 8-bit parallel, 22 pins |
| voltan masukan | 5.0V (Typ.)(VCC) |
| permohonan | IA |
