| Nombor Bahagian | CT024TN02 V.6 |
| Jenama | Innolux |
| Saiz | 2.4 |
| Permohonan | Mobile Phone |
| Resolusi | 240×320 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 300:1 |
| Warna | 65K |
| Lampu latar | WLED |
| Antara muka | |
| jenama | Innolux |
| model | CT024TN02 V.6 |
| saiz pepenjuru | 2.4 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 240(RGB)×320 [QVGA] 166PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 36.72(H)×48.96(V) mm |
| garis besar malap. | - |
| kecerahan | - |
| nisbah kontras | 300:1 (Typ.) (TM) |
| arah pandang | 12 o'clock |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 45/45/50/20 (Typ.)(CR≥10) |
| mod operasi | TN, Normally White, Transmissive |
| warna sokongan | 65K 60% NTSC |
| sumber cahaya | WLED |
| berat badan | - |
| direka untuk | Mobile Phone |
| kadar bingkai | - |
| panel sentuh | 4-wire Resistive Touch |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
