| Nombor Bahagian | CLAA140WA01 |
| Jenama | CPT |
| Saiz | 14.0 |
| Permohonan | NBPC |
| Resolusi | 1280×768 |
| Komposisi | LCM |
| Kecerahan | 185 |
| CR | 350:1 |
| Warna | 262K |
| Lampu latar | CCFL |
| Antara muka | LVDS |
| jenama panel | CPT |
| model panel | CLAA140WA01 1 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 14.0 inch |
| resolusi | 1280(RGB)×768 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 305.28×183.168 mm |
| garis besar | 320×199×5.7 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 185 cd/m² (Typ.) |
| nisbah kontras | 350:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 9/16 (Typ.)(Tr/Td) |
| sudut pandangan | 40/40/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | 1 pcsCCFLWithout Driver |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
