| Nombor Bahagian | CLAA102NA0ACG |
| Jenama | CPT |
| Saiz | 10.2 |
| Permohonan | PDVD |
| Resolusi | 1024×600 |
| Komposisi | LCM |
| Kecerahan | 220 |
| CR | 400:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | CPT |
| model panel | CLAA102NA0ACG |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 10.2 inch |
| resolusi | 1024(RGB)×600 , WSVGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 222.72×130.5 mm |
| garis besar | 235.2×145.9×6.1 mm |
| permukaan | Glare (Haze 0%), Hard coating (3H) |
| kecerahan | 220 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | 262K (6-bit) |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| sudut pandangan | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 30 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | PDVD |
| CLAA101FP01 | CPT | 10.1 | 1920×1200 |
| CLAA101FP05 XG | CPT | 10.1 | 1920×1200 |
| CLAA101NB03A | CPT | 10.1 | 1024×600 |
| CLAA101ND06CW | CPT | 10.1 | 1024×600 |
| CLAA101WA01A | CPT | 10.1 | 1366×768 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| CLAA101WH13LE | CPT | 10.1 | 1280×800 |
| CLAA102NA0ACG | CPT | 10.2 | 1024×600 |
| CLAA102NA0DCW | CPT | 10.2 | 1024×600 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| A070VW01 V2 | AUO | 7.0 | 800×480 |
| CLAA102NA0ACG | CPT | 10.2 | 1024×600 |
| CLAA102NA0ACW | CPT | 10.2 | 1024×600 |
| CLAA102NA1BCN | CPT | 10.2 | 1024×600 |
| CLAA102NA2CCN | CPT | 10.2 | 1024×600 |
| LQ050T3GG01 | SHARP | 5.0 | 400×234 |
| LTA055B0R0A | TOSHIBA | 5.5 | 480×234 |
| LTM06C381 | TOSHIBA | 5.8 | 800×480 |
