| Nombor Bahagian | CLAA101WK07 XN |
| Jenama | CPT |
| Saiz | 10.1 |
| Permohonan | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | WLED |
| Antara muka | |
| jenama | CPT |
| saiz pepenjuru | 10.1 inch |
| format piksel | 1280(RGB)×720 [WXGA] 144PPI |
| kawasan aktif | 224.64(H)×126.36(V) mm |
| kawasan bezel | 227.64(H)×129.36(V) mm |
| kecerahan | 600 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| warna sokongan | 262K/16.7M 70% NTSC |
| berat badan | 430g (Typ.) |
| kadar bingkai | 60Hz |
| model | CLAA101WK07 XN |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 238.8(H)×148.05(V) ×8.7(D) mm |
| rawatan | Antiglare (Haze 25%), Hard coating (3H) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| mod operasi | HFFS, Normally Black, Transmissive |
| sumber cahaya | WLED [6S5P] , 30K hours , W/O Driver |
| direka untuk | Automotive Display |
| panel sentuh | Without |
