| Nombor Bahagian | CLAA101WK06 XN |
| Jenama | CPT |
| Saiz | 10.1 |
| Permohonan | Automotive Display |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 900:1 |
| Warna | 262K/16.7M |
| Lampu latar | 6S5P |
| Antara muka | LVDS |
| jenama panel | CPT |
| model panel | CLAA101WK06 XN |
| saiz panel | 10.1" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1280(RGB)×720, WXGA, 144PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 224.64(W)×126.36(H) mm |
| pembukaan bezel | 227.64(W)×129.36(H) mm |
| saiz garis besar | 238.8(W)×148.05(H) ×8.7(D) mm |
| permukaan | Antiglare (Haze 25%), Hard coating (3H) |
| kecerahan | 600 cd/m² (Typ.) |
| nisbah kontras | 900:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | HFFS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| warna paparan | 262K/16.7M 70% NTSC |
| jenis lampu | 6S5P WLED , 30K hours , Without Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | 430g (Typ.) |
| permohonan | Automotive Display |
| antara muka isyarat | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| voltan masukan | 3.3/12.4/24.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| persekitaran | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
