| Nombor Bahagian | CLAA101FP0J XG |
| Jenama | CPT |
| Saiz | 10.1 |
| Permohonan | Industrial Outdoor H |
| Resolusi | 1920×1200 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 750:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | CPT |
| model panel | CLAA101FP0J XG |
| saiz panel | 10.1" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1200, WUXGA, 225PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 216.576(W)×135.36(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 228.99(W)×154.4(H) ×5.5(D) mm |
| permukaan | Antiglare, Hard coating |
| kecerahan | 1200 cd/m² (Typ.) |
| nisbah kontras | 750:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | HFFS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| warna paparan | 16.7M 50% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| kekerapan | 60Hz |
| skrin sentuh | Without |
| berat panel | TBD |
| permohonan | Industrial Outdoor High Brightness |
| antara muka isyarat | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -10 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
