| Nombor Bahagian | CLAA080WQ05 XN |
| Jenama | CPT |
| Saiz | 8.0 |
| Permohonan | Pad & Tablet Industr |
| Resolusi | 800×1280 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | 3S7P |
| Antara muka | |
| pengilang | CPT |
| saiz skrin | 8.0 inch |
| nombor piksel | 800(RGB)×1280 (WXGA) 188PPI |
| kawasan aktif (mm) | 107.64 × 172.224 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 350 (Typ.)(cd/m²) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 58% NTSC |
| jisim | 115g (Max.) |
| kadar segar semula | 60Hz |
| nama model | CLAA080WQ05 XN |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 114.6 × 184.7 × 4.56 (H×V×D) |
| rawatan | Hard coating (3H) |
| nisbah kontras | 800 : 1 (Typ.) (TM) |
| mod kerja | HFFS, Normally Black, Transmissive |
| tindak balas | 30 (Typ.)(Tr+Td) ms |
| lampu latar | 3S7P WLED , 15K hours , No Driver |
| digunakan untuk | Pad & Tablet Industrial |
| skrin sentuh | Without |
