| Nombor Bahagian | CLAA080NA73 CW |
| Jenama | CPT |
| Saiz | 8.0 |
| Permohonan | Industrial Automotiv |
| Resolusi | 1024×600 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 262K/16.7M |
| Lampu latar | 3S13P |
| Antara muka | |
| jenama panel | CPT |
| saiz panel | 8.0" |
| resolusi | 1024(RGB)×600, WSVGA, 148PPI |
| kawasan paparan | 176.64(W)×99.36(H) mm |
| saiz garis besar | 192.8(W)×116.9(H) ×8.35(D) mm |
| kecerahan | 600 cd/m² (Typ.) |
| sudut pandangan | 75/75/60/70 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K/16.7M 50% NTSC |
| kekerapan | 60Hz |
| berat badan | 220g (Typ.) |
| model panel | CLAA080NA73 CW |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | 180.1(W)×103.4(H) mm |
| permukaan | Antiglare |
| nisbah kontras | 800:1 (Typ.) (TM) |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 12 (Typ.)(Tr+Td) |
| jenis lampu | 3S13P WLED , 30K hours , Without Driver |
| skrin sentuh | Without |
| permohonan | Industrial Automotive Display |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
