| Nombor Bahagian | CLAA070WQ62 XG |
| Jenama | CPT |
| Saiz | 7.0 |
| Permohonan | Pad & Tablet |
| Resolusi | 800×1280 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | CPT |
| saiz pepenjuru | 7.0 inch |
| format piksel | 800(RGB)×1280 [WXGA] 215PPI |
| kawasan aktif | 94.2(H)×150.72(V) mm |
| kawasan bezel | - |
| kecerahan | 350 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| warna sokongan | 16.7M 70% NTSC |
| berat badan | - |
| kadar bingkai | 60Hz |
| jenis antara muka | MIPI (4 data lanes) , 39 pins FPC |
| bekalan kuasa | 1.8/3.3/15/-10V (Typ.)(VDDI/VCI/VGH/VGL) |
| persekitaran | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model | CLAA070WQ62 XG |
| menaip | a-Si TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 99.6(H)×161.62(V) ×4.05(D) mm |
| rawatan | Hard coating |
| nisbah kontras | 800:1 (Typ.) (TM) |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| mod operasi | FFS, Normally Black, Transmissive |
| sumber cahaya | WLED [3S6P] , 15K hours , W/O Driver |
| direka untuk | Pad & Tablet |
| panel sentuh | On-Cell Touch |
