| Nombor Bahagian | CLAA070WA03 |
| Jenama | CPT |
| Saiz | 7.0 |
| Permohonan | VDP |
| Resolusi | 480×234 |
| Komposisi | LCM |
| Kecerahan | 350 |
| CR | 400:1 |
| Warna | Full color |
| Lampu latar | CCFL |
| Antara muka | Analog |
| jenama panel | CPT |
| model panel | CLAA070WA03 |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 7.0 inch |
| resolusi | 480(RGB)×234 |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 154.08×86.58 mm |
| garis besar | 164.9×100 mm |
| permukaan | Antiglare |
| kecerahan | 350 cd/m² (Typ.) |
| nisbah kontras | 400:1 (Typ.) |
| warna paparan | Full color |
| masa tindak balas | 30 (Typ.)(Tr+Td) |
| sudut pandangan | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| jenis lampu | 1 pcsCCFL |
| antara muka isyarat | TFT Specific Analog RGB, 26 pins |
| voltan masukan | 5/5/15/-6V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| permohonan | VDP |
