| Nombor Bahagian | CLAA069LA0HCW |
| Jenama | CPT |
| Saiz | 7.0 |
| Permohonan | Automotive Display |
| Resolusi | 800×480 |
| Komposisi | a-Si TFT-LCD , LCM |
| Kecerahan | |
| CR | |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | |
| jenama panel | CPT |
| saiz panel | 7.0" |
| resolusi | 800(RGB)×480, WVGA, 134PPI |
| kawasan paparan | 156.6(W)×81.6(H) mm |
| sudut pandangan | 75/75/60/70 (Typ.)(CR≥10) |
| pandangan terbaik pada | 6 o'clock |
| warna paparan | 262K 70% NTSC |
| kekerapan | 60Hz |
| berat badan | 165g (Typ.) |
| model panel | CLAA069LA0HCW |
| jenis panel | a-Si TFT-LCD , LCM |
| format piksel | RGB Vertical Stripe |
| pembukaan bezel | - |
| mod paparan | TN, Normally White, Transmissive |
| masa tindak balas | 20 (Typ.)(Tr+Td) |
| jenis lampu | WLED |
| skrin sentuh | Without |
| permohonan | Automotive Display |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
