| Nombor Bahagian | CC500PV1D |
| Jenama | PANDA |
| Saiz | 50 |
| Permohonan | TV Sets |
| Resolusi | 3840×2160 |
| Komposisi | CELL, Oxide TFT-LC |
| Kecerahan | |
| CR | 5000:1 |
| Warna | 1.07B |
| Lampu latar | No |
| Antara muka | V-by-One |
| pengilang | PANDA |
| nama model | CC500PV1D |
| saiz skrin | 50 inch |
| jenis skrin | CELL, Oxide TFT-LCD |
| nombor piksel | 3840(RGB)×2160 (UHD) 89PPI |
| susunan | RGB Vertical Stripe |
| kawasan aktif (mm) | 1095.8 × 616.41 (H×V) |
| garis besar (mm) | 1106.84 × 628.01 × 1.37 (H×V×D) |
| kawasan bezel (mm) | - |
| rawatan | Antiglare, Hard coating (2H) |
| kecerahan | 0 cd/m² |
| nisbah kontras | 5000 : 1 (Typ.) (TM) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| tindak balas | 8 (Typ.)(G to G) ms |
| pandangan yang baik di | Symmetry |
| mod kerja | UV2A, Normally Black, Transmissive |
| ketebalan kaca | 0.50+0.50 mm |
| ketransmisian | 5.2% (Typ.)(with Polarizer) |
| kedalaman warna | 1.07B 70% NTSC |
| lampu latar | No B/L |
| jisim | 2.12Kgs (Typ.) |
| digunakan untuk | TV Sets |
| kadar segar semula | 60Hz |
| skrin sentuh | Without |
| senarai ic pemandu | Built-in COF 12 source chips |
| jenis isyarat | V-by-One 8 lane , Connector 51 pins |
| bekalan voltan | 12.0V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
