| Nombor Bahagian | C101EAN02.0 |
| Jenama | AUO |
| Saiz | 10.1 |
| Permohonan | Outdoor High Brightn |
| Resolusi | 1280×720 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | MIPI |
| jenama | AUO |
| model | C101EAN02.0 |
| saiz pepenjuru | 10.1 inch |
| menaip | a-Si TFT-LCD, LCM |
| format piksel | 1280(RGB)×720 [WXGA] 145PPI |
| konfigurasi | RGB Vertical Stripe |
| kawasan aktif | 223.68(H)×125.82(V) mm |
| garis besar malap. | 238.6(H)×148(V) ×10.8(D) mm |
| kawasan bezel | 226.78(H)×132.22(V) mm |
| rawatan | Antiglare |
| kecerahan | 780 cd/m² (Typ.) |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| arah pandang | Symmetry |
| masa tindak balas | 20/20 (Max.)(Tr/Td) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod operasi | AHVA, Normally Black, Transmissive |
| warna sokongan | 16.7M 98% sRGB |
| sumber cahaya | WLED [8S3P] , 10K hours , W/O Driver |
| berat badan | 400±40g |
| direka untuk | Outdoor High Brightness Automotive Display |
| kadar bingkai | 60Hz |
| panel sentuh | Without |
| jenis antara muka | MIPI (4 data lanes) , 40 pins FPC |
| bekalan kuasa | 3.3/3.3V (Typ.)(VDD/VDDA) |
| persekitaran | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
