| Nombor Bahagian | BV050HDE-NBA-3Q00 |
| Jenama | BOE |
| Saiz | 5.0 |
| Permohonan | Mobile Phone |
| Resolusi | 720×1280 |
| Komposisi | a-Si TFT-LCD, CELL |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | No |
| Antara muka | |
| jenama panel | BOE |
| model panel | BV050HDE-NBA-3Q00 |
| saiz panel | 5.0" |
| jenis panel | a-Si TFT-LCD, CELL |
| resolusi | 720(RGB)×1280, WXGA, 294PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 62.1(W)×110.4(H) mm |
| pembukaan bezel | - |
| kecerahan | 0 cd/m² |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| sudut pandangan | 80/80/80/80 (Typ.)(CR≥10) |
| mod paparan | ADS, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Td) |
| warna paparan | 16.7M 70% NTSC |
| jenis lampu | No B/L |
| kekerapan | - |
| skrin sentuh | Without |
| berat panel | - |
| permohonan | Mobile Phone |
| persekitaran | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| A050FW03 V0 | AUO | 5.0 | 480×272 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| CLAN050LH21 1XB | CPT | 5.0 | 540×960 |
| CLAN050LL31 1XG | CPT | 5.0 | 480×800 |
| H497TLB01.4 | AUO | 5.0 | 720×1280 |
| HJ050NA-01I | Innolux | 5.0 | 800×480 |
| LMS500HF05 | Samsung | 5.0 | 480×272 |
| LQ5AW136 | SHARP | 5.0 | 320×234 |
| P50AD2 | E Ink | 5.0 | 320×234 |
| PA050XS1 | E Ink | 5.0 | 320×234 |
