| Nombor Bahagian | BH156EA2S |
| Jenama | No Brand |
| Saiz | 15.6 |
| Permohonan | Laptop |
| Resolusi | 1920×1080 |
| Komposisi | Oxide TFT-LCD , LCM |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama | No Brand |
| saiz pepenjuru | 15.6 inch |
| format piksel | 1920(RGB)×1080 [FHD] 141PPI |
| kawasan aktif | 344.16(H)×193.59(V) mm |
| kawasan bezel | - |
| kecerahan | 250 cd/m² (Typ.) |
| arah pandang | Symmetry |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| warna sokongan | 262K 45% NTSC |
| gaya bentuk | Slim (PCBA Flat, T≤3.2mm) |
| kadar bingkai | 60Hz |
| jenis antara muka | eDP (2 Lanes) , 30 pins Connector |
| bekalan kuasa | 3.3V (Typ.) |
| persekitaran | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | BH156EA2S |
| menaip | Oxide TFT-LCD , LCM |
| konfigurasi | RGB Vertical Stripe |
| garis besar malap. | 359.5(H)×223.8(V) ×3.2(D) mm |
| rawatan | Antiglare |
| nisbah kontras | 1000:1 (Typ.) (TM) |
| masa tindak balas | 25 (Typ.)(Tr+Tf) |
| mod operasi | FFS, Normally Black, Transmissive |
| sumber cahaya | WLED [4S10P] , 10K hours , With LED Driver |
| direka untuk | Laptop |
| panel sentuh | Without |
| B156XTN03.2 | AUO | 15.6 | 1366×768 |
| CLAA156WA01A | CPT | 15.6 | 1366×768 |
| CLAA156WA11A | CPT | 15.6 | 1366×768 |
| LP156WF4-SPB1 | LG Display | 15.6 | 1920×1080 |
| LP156WF6-SPK1 | LG Display | 15.6 | 1920×1080 |
| LTN156AT32-L01 | Samsung | 15.6 | 1366×768 |
| LTN156HT02-B01 | Samsung | 15.6 | 1920×1080 |
| N156B6-L3D | Innolux | 15.6 | 1366×768 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
