| Nombor Bahagian | B173ZAN01.1 |
| Jenama | AUO |
| Saiz | 17.3 |
| Permohonan | Laptop |
| Resolusi | 3840×2160 |
| Komposisi | LCM , a-Si TFT-LCD |
| Kecerahan | |
| CR | 1000:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| pengilang | AUO |
| saiz skrin | 17.3 inch |
| nombor piksel | 3840(RGB)×2160 (UHD) 255PPI |
| kawasan aktif (mm) | 382.12 × 214.94 (H×V) |
| kawasan bezel (mm) | - |
| kecerahan | 300 cd/m² (Typ.) |
| sudut pandangan | 89/89/89/89 (Typ.)(CR≥10) |
| pandangan yang baik di | Symmetry |
| kedalaman warna | 16.7M 100% Adobe RGB |
| bentuk garis besar | Flat (PCBA Flat, T3.4~4.0mm) |
| kadar segar semula | 60Hz |
| jenis isyarat | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| bekalan voltan | 3.3V (Typ.) |
| maks. penilaian | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| nama model | B173ZAN01.1 (AUO119B) |
| jenis skrin | LCM , a-Si TFT-LCD |
| susunan | RGB Vertical Stripe |
| garis besar (mm) | 398.1 × 252.5 × 4 (H×V×D) |
| rawatan | Antiglare, Hard coating (3H) |
| nisbah kontras | 1000 : 1 (Typ.) (TM) |
| tindak balas | 27 (Typ.)(Tr+Td) ms |
| mod kerja | AHVA, Normally Black, Transmissive |
| lampu latar | WLED , 15K hours , With LED Driver |
| digunakan untuk | Laptop |
| skrin sentuh | Without |
