| Nombor Bahagian | B173HAN04.9 |
| Jenama | AUO |
| Saiz | 17.3 |
| Permohonan | Laptop Gaming |
| Resolusi | 1920×1080 |
| Komposisi | a-Si TFT-LCD, LCM |
| Kecerahan | |
| CR | 800:1 |
| Warna | 16.7M |
| Lampu latar | WLED |
| Antara muka | eDP |
| jenama panel | AUO |
| model panel | B173HAN04.9 (AUO978F) |
| saiz panel | 17.3" |
| jenis panel | a-Si TFT-LCD, LCM |
| resolusi | 1920(RGB)×1080, FHD, 127PPI |
| format piksel | RGB Vertical Stripe |
| kawasan paparan | 381.888(W)×214.812(H) mm |
| pembukaan bezel | - |
| saiz garis besar | 389.89(W)×238.31(H) ×3.5(D) mm |
| permukaan | Antiglare, Hard coating (3H) |
| kecerahan | 250 cd/m² (Typ.) |
| nisbah kontras | 800:1 (Typ.) (TM) |
| sudut pandangan | 85/85/85/85 (Typ.)(CR≥10) |
| mod paparan | AHVA, Normally Black, Transmissive |
| pandangan terbaik pada | Symmetry |
| masa tindak balas | 25 (Typ.)(Tr+Tf) |
| warna paparan | 16.7M 45% NTSC |
| jenis lampu | WLED , 15K hours , With LED Driver |
| kekerapan | 144Hz |
| skrin sentuh | Without |
| gaya bentuk | Flat (PCBA Flat, T3.4~4.0mm) |
| permohonan | Laptop Gaming |
| antara muka isyarat | eDP (4 Lanes) , eDP1.3 , 40 pins Connector |
| voltan masukan | 3.3V (Typ.) |
| persekitaran | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B173HAN01.0 | AUO | 17.3 | 1920×1080 |
| B173HTN01.1 | AUO | 17.3 | 1920×1080 |
| B173HW01 V4 | AUO | 17.3 | 1920×1080 |
| B173HW01 V5 | AUO | 17.3 | 1920×1080 |
| B173HW02 V1 | AUO | 17.3 | 1920×1080 |
| B173RW01 V2 HW7A | AUO | 17.3 | 1600×900 |
| B173RW01 V5 | AUO | 17.3 | 1600×900 |
| HSD173PUW1-A | HannStar | 17.3 | 1920×1080 |
| LP173WD1-TLC2 | LG Display | 17.3 | 1600×900 |
| LP173WD1-TLN2 | LG Display | 17.3 | 1600×900 |
