| Nombor Bahagian | B156XW02 V2 HW4A |
| Jenama | AUO |
| Saiz | 15.6 |
| Permohonan | NBPC |
| Resolusi | 1366×768 |
| Komposisi | LCM |
| Kecerahan | 200 |
| CR | 500:1 |
| Warna | 262K |
| Lampu latar | WLED |
| Antara muka | LVDS |
| jenama panel | AUO |
| model panel | B156XW02 V2 HW4A 2 Compatible model |
| jenis panel | a-Si TFT-LCD , LCM |
| saiz panel | 15.6 inch |
| resolusi | 1366(RGB)×768 , WXGA |
| mod paparan | TN, Normally White, Transmissive |
| kawasan aktif | 344.232×193.536 mm |
| garis besar | 359.3×209.5×5.5 mm |
| gaya bentuk | Wedge (PCBA Bent, Depth ≥5.2mm) |
| permukaan | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| kecerahan | 200 cd/m² (Typ.) |
| nisbah kontras | 500:1 (Typ.) |
| warna paparan | 262K (6-bit), CIE193160% |
| masa tindak balas | 6/2 (Typ.)(Tr/Td) |
| sudut pandangan | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| kekerapan | 60Hz |
| jenis lampu | WLEDEmbedded (LED Driver) |
| antara muka isyarat | LVDS (1 ch, 6-bit), 40 pins |
| voltan masukan | 3.3V (Typ.) |
| permohonan | NBPC |
| B156HB01 V0 | AUO | 15.6 | 1920×1080 |
| B156XW02 V0 | AUO | 15.6 | 1366×768 |
| B156XW02 V2 HW4A | AUO | 15.6 | 1366×768 |
| B156XW02 V3 | AUO | 15.6 | 1366×768 |
| B156XW02 V6 | AUO | 15.6 | 1366×768 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| LM156WH1-TLE1 | LG Display | 15.6 | 1366×768 |
| LP156WH2-TLBA | LG Display | 15.6 | 1366×768 |
| LP156WHB-TPA1 | LG Display | 15.6 | 1366×768 |
| N156HGE-LA1 | Innolux | 15.6 | 1920×1080 |
| B140RW03 V1 | AUO | 14.0 | 1600×900 |
| B140XW03 V1 | AUO | 14.0 | 1366×768 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| LP133WH2-TLE1 | LG Display | 13.3 | 1366×768 |
| LTD121EA4XY | TOSHIBA | 12.1 | 1024×768 |
| LTN133AT16-S01 | Samsung | 13.3 | 1280×800 |
| LTN140AT20-P02 | Samsung | 14.0 | 1366×768 |
| LTN150PF-L03 | Samsung | 15.0 | 1400×1050 |
| LTN156AT02-B04 | Samsung | 15.6 | 1366×768 |
| LTN170BT06-G01 | Samsung | 17.0 | 1440×900 |
